Controls
Instruments/Features/Controls
Windshield Adjustment
Use the motorized windshield adjustment switch (if
equipped) to adjust the windshield. See page 67. If the motor-
cycle is not equipped with this feature, you can manually
adjust the windshield.
1. Park the motorcycle on a firm, level surface. Turn the key
to the OFF position.
2. Remove the windshield trim panel. See page 205.
3. Remove the retaining clip.
4. Hold slight downward pressure on the bottom of the
windshield (it is under slight upward spring pressure).
Remove the clevis pin.
5. Slide the windshield inner bracket to align with one of the
optional holes in the outer bracket. Reinstall the clevis
pin. Reinstall the retaining clip in the clevis pin.
6. Reinstall the windshield trim panel.
