Manual

EN

Handleiding

NL

Manuel

FR

Anleitung

DE

Manual

ES

Manuale

IT

Appendix

MultiPlus 1600VA

MultiPlus 12 | 1600 | 70 230V

MultiPlus 24 | 1600 | 40 230V

MultiPlus 48 | 1600 | 20 230V

Table of Contents

Questions and Answers

B
Brenda CaldwellAug 4, 2025
What to do if the alarm LED flashes on my Victron energy MultiPlus 1600VA?
- B
  Brian JohnsonAug 4, 2025
  If the alarm LED on your Victron energy Inverter is flashing, it could be due to several reasons: * The DC input voltage is low: Charge the battery or check the battery connections. * The ambient temperature is too high: Place the inverter in a cool and well-ventilated room, or reduce the load. * The load on the inverter is higher than the nominal load: Reduce the load. * Voltage ripple on the DC input exceeds 1.25Vrms: Check the battery cables and terminals, and increase battery capacity if necessary. * Low battery voltage and excessive load: Charge the batteries, reduce the load, install batteries with a higher capacity and use shorter and/or thicker battery cables.
B
Bryan CollinsAug 10, 2025
Why Victron energy Inverter battery is not being charged fully?
- A
  Alexander KingAug 10, 2025
  If the battery is not being fully charged by your Victron energy Inverter, consider the following potential causes: * Incorrect charging current: Set the charging current at between 0.1 and 0.2x battery capacity. * A defective battery connection: Check the battery terminals. * The absorption voltage has been set to an incorrect value: Adjust the absorption voltage to the correct value. * The float voltage has been set to an incorrect value: Adjust the float voltage to the correct value. * The internal DC fuse is defective: The inverter is damaged.
A
Amanda LambAug 16, 2025
Why my Victron energy MultiPlus 1600VA Inverter battery is overcharged?
- A
  Amanda CannonAug 17, 2025
  If the battery is being overcharged by your Victron energy Inverter, here are a few possible reasons: * The absorption voltage has been set to an incorrect value: Adjust the absorption voltage to the correct value. * The float voltage has been set to an incorrect value: Adjust the float voltage to the correct value. * A defective battery: Replace the battery. * The battery is too small: Reduce the charging current or use a battery with a higher capacity. * The battery is too hot: Connect a temperature sensor.
G
garzajamesAug 22, 2025
What does it mean when the alarm LED is on on my Victron energy MultiPlus 1600VA?
- A
  Alexis WilsonAug 22, 2025
  If the alarm LED is on your Victron energy Inverter, it indicates that the inverter did cut out following a pre-alarm. You should check the table for the appropriate course of action.
L
Lisa RodriguezAug 28, 2025
Why does the battery charge current drop to 0 when the absorption voltage is reached on my Victron energy MultiPlus 1600VA Inverter?
- L
  lmaysAug 28, 2025
  If the battery charge current drops to 0 when the absorption voltage is reached on your Victron energy Inverter, it could be due to: * Battery overtemperature (> 50°C): Allow battery to cool down, place battery in a cool environment and check for shorted cells. * Battery temperature sensor faulty: Unplug battery temperature sensor from the Multi. Reset the Multi by switching it off, then wait for 4 seconds and switch it on again. If the Multi now charges normally, the battery temperature sensor is faulty and needs to be replaced.

Summary

SAFETY INSTRUCTIONS

Installation Safety Guidelines

Guidelines for safely installing the product, including grounding and wiring.

PRODUCT DESCRIPTION

Battery Charging System

Explains adaptive 4-stage charging, BatterySafe, and absorption time.

OPERATION MODES

INSTALLATION AND CONNECTIONS

Location and Battery Cable Setup

Requirements for product location and steps for connecting battery cables.

AC Cabling and Optional Connections

Instructions for AC cabling and an overview of optional connections.

CONFIGURATION

Settings Explanation and DIP Switches

MAINTENANCE

TROUBLE SHOOTING TABLE

TECHNICAL DATA

APPENDICES

Appendix E: Charge Algorithm

Detailed explanation of the 4-stage charging algorithm and its modes.

Summary

SAFETY INSTRUCTIONS

Installation Safety Guidelines

Guidelines for safely installing the product, including grounding and wiring.

PRODUCT DESCRIPTION

Battery Charging System

Explains adaptive 4-stage charging, BatterySafe, and absorption time.

OPERATION MODES

INSTALLATION AND CONNECTIONS

Location and Battery Cable Setup

Requirements for product location and steps for connecting battery cables.

AC Cabling and Optional Connections

Instructions for AC cabling and an overview of optional connections.

CONFIGURATION

Settings Explanation and DIP Switches

MAINTENANCE

TROUBLE SHOOTING TABLE

TECHNICAL DATA

APPENDICES

Appendix E: Charge Algorithm

Detailed explanation of the 4-stage charging algorithm and its modes.

Victron energy MultiPlus 1600VA Specifications

General

Brand	Victron energy
Model	MultiPlus 1600VA
Category	Inverter
Language	English
