Victron energy Quattro 48/10000/140 User Manual

23
EN NL FR DE ES SV IT Appendix
8. TECHNICAL SPECIFICATION
Quattro
12/5000/220-100/100
24/5000/120-100/100
48/5000/70-100/100
24/8000/200-100/100
48/8000/110-100/100
48/10000/140-
100/100
48/15000/200-
100/100
PowerControl / PowerAssist
Yes
Integrated Transfer switch
Yes
AC inputs (2x)
Input voltage range: 187-265 VAC Input frequency: 45 – 65 Hz Power factor: 1
Maximum feed through current (A)
2x100
2x100
2x100
2x100
INVERTER
Input voltage range (V DC)
9,5 – 17V 19 – 33V 38 – 66V
Output
(1)
Output voltage: 230 VAC ± 2% Frequency: 50 Hz ± 0,1%
Cont. output power at 25°C (VA)
(3)
5000
8000
10000
15000
Cont. output power at 25°C (W)
4000
6500
8000
12000
Cont. output power at 40°C (W)
3700
5500
6500
10000
Cont. output power at 65°C (W)
3000
3600
4500
7000
Peak power (W)
10000
16000
20000
25000
Maximum efficiency (%)
94 / 94 / 95
94 / 96
96
96
Zero load power (W)
30 / 30 / 35
45 / 50
55
80
Zero load power in AES mode (W)
20 / 25 / 30
30 / 30
35
50
Zero load power in Search mode (W)
10 / 10 / 15
10 / 20
20
30
CHARGER
Charge voltage 'absorption' (V DC)
14,4 / 28,8 / 57,6
28,8 / 57,6
57,6
57,6
Charge voltage 'float' (V DC)
13,8 / 27,6 / 55,2
27,6 / 55,2
55,2
55,2
Storage mode (V DC)
13,2 / 26,4 / 52,8
26,4 / 52,8
52,8
52,8
Charge current house battery (A) (4)
220 / 120 / 70
200 / 110
140
200
Charge current starter battery (A)
4 (12V and 24V models only)
Battery temperature sensor
Yes
GENERAL
Auxiliary output (A) (5)
50
50
50
50
Programmable relay (6)
3x
3x
3x
3x
Protection (2)
a-g
VE.Bus communication port
For parallel and three phase operation, remote monitoring and system integration
General purpose com. port
2x
2x
2x
2x
Remote on-off
Yes
Common Characteristics
Operating temp.: -40 to +65˚C Humidity (non-condensing): max. 95%
ENCLOSURE
Common Characteristics
Material & Colour: aluminium (blue RAL 5012) Protection category: IP 21
Battery-connection
Four M8 bolts (2 plus and 2 minus connections)
230 V AC-connection
Bolts M6
Bolts M6
Bolts M6
Bolts M6
Weight (kg)
34 / 30 / 30
45 / 41
45
72
Dimensions (hxwxd in mm)
470 x 350 x 280
444 x 328 x 240
444 x 328 x 240
470 x 350 x 280 470 x 350 x 280 572 x 488 x 344
STANDARDS
Safety
EN-IEC 60335-1, EN-IEC 60335-2-29, EN-IEC 62109-1
Emission, Immunity
EN 55014-1, EN 55014-2, EN-IEC 61000-3-2, EN-IEC 61000-3-3, EN-IEC 61000-6-3, EN-IEC 61000-6-2, EN-
IEC 61000-6-1
Vehicles, aftermarket
12V and 24V models: EN 50498
Anti-islanding
See our website
1) Can be adjusted to 60 HZ; 120 V 60 Hz
on request
2) Protection key:
a) output short circuit
b) overload
c) battery voltage too high
d) battery voltage too low
e) temperature too high
f) 230 VAC on inverter output
g) input voltage ripple too high
3) Non-linear load, crest factor 3:1
4) At 25˚C ambient
5) Switches off when no external AC source available
6) Programmable relay that can a.o. be set for general alarm,
DC under voltage or genset start/stop function
AC rating: 230 V / 4 A
DC rating: 4 A up to 35 VDC, 1 A up to 60 VDC

Victron energy Quattro 48/10000/140 Specifications

General

Model	Quattro 48/10000/140
Input Voltage	48 VDC
AC Output Power	10000 VA
Output Voltage	230 VAC
Charge Current	140 A
Efficiency	94%
Input Voltage Range	38 - 66 VDC
Transfer Time	20 ms
AC Input Current	50 A
AC Input Voltage Range	187-265 VAC
Parallel Operation	Yes, up to 6 units
Output Frequency	50 Hz
Protection	Overload, short circuit
