ITEM HOW TO DISASSEMBLE AND ASSEMBLE DRAWINGS
FILTER UNIT
ASSEMBLY
1.
Pull out the filter unit from over flow filter lock, use
3.
Set back to the original position, inset the bottom
(Fig 1)
(Fig 2)
(Fig 3)
6. SERVICE INFORMATION
19
Over Flow Filter with Filter Unit
use fingers to press and pull out (Fig 1)
first as shown press down and lock as the arrow (Fig 3)
2.
Turn lint filter inside out, and rinse the dirt from filter.
(Fig 2)
6-2. DISASSEMBLY INFORMATION
