Terminal Connections
Terminal Function
-
Main Databus input from any main door panel(s) towards the Art.2206N bus exchanger
MB
-
Local Databus input from the block door panel towards the bus Art.2206N bus exchanger
LB
-
Databus (bus out) output from the Art.2206N bus exchanger towards the audio and/or
videophones in the block
BO
BS Busy signal input/output
- 0V power input (ground)
+12 12Vdc power input
V2O Balanced video signal output V2 towards the videophones in the block
V/V1O
Balanced video signal V1 or composite video signal V (see JP2, JP3 settings) output towards
the videophones in the block
V2L Balanced video signal input V2 from the block door panel
V/V1L
Balanced video signal V1 or composite video signal V (see JP2, JP3 settings) input from the
block door panel
V2P Amplied balanced video signal output V2 towards the videophones in the block
V/V1P
Amplied balanced video signal V1 or composite video signal V (see JP2, JP3 settings) output
towards the videophones in the block
V2 Balanced video signal input/output V2 to and from the main door panel(s)
V/V1
Balanced video signal V1 or composite video signal V (see JP2, JP3 settings) input/output to
and from the main door panel(s)
V2 Balanced video signal input/output V2 to and from the main door panel(s)
V/V1
Balanced video signal V1 or composite video signal V (see JP2, JP3 settings) input/output to
and from the main door panel(s)
Technical Specications
Input Voltage : 12Vdc +5% -10%
Current : 100mA (max.)
Module Dimensions : 157.5mm (L) x 105mm (W) x 65mm (D)
Working Temp. : -10
o
C +50
o
C
