Videx 6256 Installation Handbook

66250457-EN - V5.1 - 31/08/20
- 3 -
VK4K/6256 Series “6 wire Bus” videokit
VK4K/6256 Series - Installation handbook
System components and available versions
VK4K/6256
Colour videokit.
50
43,8
135,0
160,0
45,0 22,7
15,7
143,0
120,0
45,0
INDOOR
STATION
Videophone
Art.6256
pag. 20
ACCESSORIES
Power supply
Art.850K
pag. 5
Video distributor
Art.316N
pag. 23
OUTDOOR
STATION
Camera unit
Art.4833
pag. 8
Flush
Mounting
Surface
Mounting
Fig. 1 - VK4K/6256 components (measures in mm)
ONE WAY VERSIONS
VK4K-1/6256 - ush mounting
1 Outdoor station composed of:
1 Art.4833-1: 1 button camera unit
1 Art.4851: Flush mounting box
1 Colour videophone
Art.6256
1 Power supply
Art.850K
VK4K-1S/6256 - surface mounting
1 Outdoor station composed of:
1 Art.4833-1: 1 button camera unit
1 Art.4881: Surface mounting box
1 Colour videophone
Art.6256
1 Power supply
Art.850K
TWO WAY VERSIONS
VK4K-2/6256 - ush mounting
1 Outdoor station composed of:
1 Art.4833-2: 2 button camera unit
1 Art.4851: Flush mounting box
2 Colour videophones
Art.6256
2 Power supplies
Art.850K
1 Video distributor
Art.316N
VK4K-2S/6256 - surface mounting
1 Outdoor station composed of:
1 Art.4833-2: 2 button camera unit
1 Art.4881: Surface mounting box
2 Colour videophones
Art.6256
2 Power supplies
Art.850K
1 Video distributor
Art.316N
