Vidikron VERSION 50 - Front and Top View Components

10
Vidikron Vision Model 50 Owner’s Operating Manual
Overview
1. Vidikron Logo
Can be rotated to match floor or
ceiling installation. See “Vidikron
Logo” on page 15.
2. Top IR Sensor
3. Status LEDs
See “Control Panel” on page 13.
4. Intake Vent
5. Exhaust Vent
6. Front IR Sensor
7. Projection Lens
Front / Top View
