Viessmann Cascade control unit - Safety and Monitoring Equipment

29
Functions
Safety and monitoring equipment
Function monitoring by detecting the flow temperature
The heating system function is monitored by comparing the required and the
actual flow temperature.
A fault message is displayed if, within an adjustable period, the flow
temperature does not reach the required value less the adjustable tolerated
temperature deviation. The control unit remains in normal mode.
The fault message will be removed if the flow temperature rises above the
required flow temperature less the tolerated deviation.
Set values (multi-boiler control unit)
Tolerated (negative) deviation from the required
flow temperature.
The flow temperature must reach the required
value within the adjustable period, subject to the
tolerated deviation.
Frost protection through monitoring the flow temperature
The flow temperature will be held at the adjustable minimum value, if the
flow temperature falls below 5ĂºC.
Set values (multi-boiler control unit)
When there is a risk of frost, the flow
temperature will be held at least at the set value.
Frost protection through monitoring the outside temperature
Preconditions: "Frost protection Yes" must be configured (see pageĂ12).The
flow temperature will be held at the adjustable minimum value (see "Frost
protection through monitoring the flow temperature") , if the outside
temperature falls below 3ĂºC.
The frost protection function will be cancelled again, if the outside
temperature rises above 4ĂºC.
Operating details (multi-boiler control unit)
The frost protection function will be activated
because of low outside temperature.
5862Ă474ĂGB
Diff. flow temp.
fault 10K
Time flow temp.
fault 60 min
Min. flow temp.
frost prot. 20ºC
Frost protection
