Divicon with mixer
Note
With several Divicons, first fit the ther-
mal insulation on the right Divicon. For
the remaining Divicons, fit the insulation
from right to left.
1.2.3.
A
B
3.
2.
3.
2.
1.
A
Cut if fitting a single module to the
wall
B
Cut out the thermal insulation if
connecting with a union nut
Fitting the thermal insulation
(cont.)
