Set rotary selector:
Heating circuit affected by
the mixer
Sensors connected Rotary selector S1
Heating circuit with mixer M2 Flow temperature sensor "2"
(delivered condi-
tion)
Flow temperature sensor and
return temperature sensor
"3"
Heating circuit with mixer M3 Flow temperature sensor "4"
Flow temperature sensor and
return temperature sensor
"5"
Wall mounted and storage combi
boilers
Danger
Incorrect core assignment can
result in serious injury and dam-
age to the appliance.
Take care not to interchange
wires "L1" and "N".
Extension kit with mixer PCB
(cont.)
