Connections
23
Installation Checklist
Prior to and after the installation, use the following check list to ensure proper installation. Improper installation could create a
hazard, resulting in property damage, severe pers onal injury, or loss of life. The correct answer is “yes” to all of the following
questions.
Is t he flow direction correct?
Water flows in at bottom from the system connection and out at top 1¼”
connection?
Yes No
Is the pump electrically connected to the pump aquastat?
Yes No
Is the boiler located so that the vent pipe length is minimized?
Yes No
Is the outside vent terminal at least 1 ft. / 0.3 m above the usual snow level for
your area?
Yes No
Are all joints in the vent system siliconed and clamped tight so t hat
there are no leaks? Is the vent pipe properly supported?
Yes No
If the ECV boiler has been installed in an older piping system, has the s ystem
been flushed out to ensure debris, s cale, rust and sludge will not s ettle in boiler?
Yes No
Is the ECV vent pipe properly supported every 2 ft. / 0.6 m with metal strapping?
Yes No
Is there an adequate supply of fresh combustion air?
Yes No
Is t he outside vent terminal located on a wall away from prev ailing winds?
Yes No
5167 450 v1.4
