Checking the anode connection, fitting the fascia and cover, affixing the type plate
3.
4.
2.
A B
1.
Fig. 6
A
Magnesium anode
B
Earth cable
Note
Guide the thermometer lead through the groove in the
flange insulation.
Siting DHW cylinders (up to 300 l) (cont.)
