Checking the anode connection, fitting the fascia and cover, affixing the type plate
3.
4.
2.
A B
1.
Fig. 10
A
Protective magnesium anode
B
Earth cable
Note
Route the thermometer lead through the groove in the
EPS flange insulation.
Installation sequence
