Page #15 background image
15
The following information is required:
Serial no. (see type plate)
Position number of the part from this
parts list
Standard parts are available from your
local supplier.
With solar control module, type SM1
Version with standard pump
0001 Adjustable foot
0002 Outer jacket
0003 Type plate
0004 Edge profile fastener, internal
0005 Edge profile fastener, external
0006 Fixing part
0007 Insulating parts
0009 Gasket set G 1
0010 U-tube, solar flow
0011 Air vent plug
0012 Locking ring fitting
0013 Sheet metal retainer
0015 Solar circuit pump
0016 Safety assembly
0017 Flow meter
0018 Ball valve, solar return
0019 Ball valve handle, blue
0020 Gasket 21 x 30 x 2
0021 Seal ring R ½, mixer
0022 Strain relief
0023 KM BUS cable l = 4500 mm
0024 Solar return elbow
0025 Solar control module, type SM1
0026 Connection line
0027 Solar circuit pump connecting
cable
0028 Power cable l = 4500 mm
0030 Temperature sensor NTC
0031 Top panel
0032 Adaptor lead, collector tempera-
ture sensor
0033 Flange insulation
0034 Anode flange
0035 Cast rod anode
0036 Gasket
0037 Sensor retainer
0038 Plug
0039 Solar expansion vessel 18 l,
10 bar
0040 Cover G 2
0041 Connecting elements
0042 Bracket
0043 Vitocell 100 logo
0044 Viessmann logo
0045 Pressure gauge
0046 Solar control module, type SM1
installation and service instruc-
tions
0047 Vitocell 100 service instructions
0048 Vitocell 100 installation instruc-
tions
Parts lists
Ordering parts
5773 800 GB
