Viessmann VITOCELL 100-W Service Instructions

25
Specification with high efficiency solar circuit pump
Wilo solar circuit pump PARA 15/7
Rated voltage V~ 230
Power consumption
■ Min. W 3
■ Max. W 45
Flow indicator l/min 2 to 15
Safety valve (solar) bar
MPa
6
0.6
Max. operating temperature °C 120
Max. operating pressure bar
MPa
6
0.6
Pump curve, high efficiency solar circuit pump
0 0.5 1.0 1.5
Pump rate in m³/h
Head in m
0
2
4
6
8
2.0
A
B
D
C
A
Pressure drop curve
B
Residual head
C
Min. output
D
Max. output
Specification
Specification
(cont.)
5773 800 GB
