Viessmann Vitoconnect OPTO2 Series - Installation Sequence; Overview of the Installation and Commissioning Process

12
Steps Responsibility Page
Type OPTO2 Type OT2
Installation
1 Check system requirements. Heating contractors
IT expert
10 10
2 Insert cables. Heating contractors
System user
— 14
3 Fit wall mounting bracket for Vitoconnect. Heating contractors
System users
13 13
4 Fit wall mounting bracket for Vitotrol 100. Heating contractors
System users
— 14
5 Connect Vitoconnect to heat generator. Heating contractors — 15
Heating contractors
System user
15 —
7 Connect Vitoconnect and Vitotrol 100. Heating contractors
System users
— 16
8 Insert Vitoconnect into wall mounting bracket. Heating contractors
System users
16 16
9 Insert Vitotrol 100 into wall mounting bracket. Heating contractors
System users
— 17
10 Connect Vitoconnect to power supply. Heating contractors
System users
17 17
Commissioning
11 Check network settings. IT expert 19 19
12 Register user and set up heating system. Heating contractors
System users
19 19
Installation sequence
Overview of the installation and commissioning process
