Displayed

fault c ode

Con-

st.

Weat -

her-

com-

System

character-

istics

Cause Remedy

FF X X Burner

blocked

Internal fault Remove EMC inter-

ference. If the

equipment will not

restart, check the

boiler coding card

and r eplace, or

replace the control

unit.

Repairs

Checking the outside temperature sensor (weather-compen-

sated control units)

1. Pull plug X3 from the control unit.

Checking and acknowledging faults (cont.)

Troubleshooting

5692 537 GB
