Cleaning the burner
1. Undo nuts, remove the lid with
mixer equipment A and secure in
the maintenance position.
2. Pull the leads off ignition electro-
des B.
3. Undo Allen screw C and remove
rifling facility D.
4. Clean the restrictor, metering ring,
ignition electrodes and the flame
monitor tube.
Further details regarding the individual steps (cont.)
17
Initial start-up, inspection, maintenance
5692 536 GB
