Viessmann Vitorond 100 - Riello Burner Calibration; Barometric Draft Regulator

Initial Start-up
60
Initial Start-Up (continued)
Riello burner calibration
*1
Boiler model Model No. VR1-40 VR1-50 VR1-63
Burner model Riello 40
Series
F5 F5 F10
Fuel type oil No. 2 fuel oil
Pump pressure psig 175 175 175
Oil nozzle
Danfoss 0.85x60°xAH
*3
1.10x60°xAH 1.35x60°xAH
*2
O
i
l
n
o
z
z
l
e
Delavan 0.85x60°xA
0.85x60°xW
1.10x60°xA
*3
1.35x60°xA
1.35x60°xW
Hago 0.85x60°xH 1.10x60°xH
1.10x60°xSS
1.35x45°xSS
Oil nozzle flow rate GPH@psig 1.15@175 1.40@175 1.75@175
Air tube length inches
mm
6
5
/
16
160
6
5
/
16
160
7
178
Air tube insertion inches
mm
4¼
108
4¼
108
4¾
121
Turbulator setting 1.0 3.0 2.0
Air gate setting 3.5 3.6 2.8
*1
For VR1-40 and -50 boilers, replace installed nozzle in VR1-33 Riello burner with the appropriate nozzle packaged with
burner.
*2
Factory-installed nozzle.
*3
Nozzles must be installed by installer.
Note: The Riello burner for the VR1-33 boiler is shipped with factory setting and oil nozzle installed, and should require only
minor adjustments. For VR1-40, and -50 boilers, replace installed nozzle with nozzle packaged with burner.
Barometric draft regulator
When a barometric draft regulator is
used, adjust the barometric draft
regulator such that the over-fire draft is
0.00 to +0.01 “w.c., while the breech
draft is approximately -0.02 “w.c.
During operation of the burner, the
barometric draft regulator installed in
the vent system must move freely.
5671 044 v1.0
