Set-up
16
Insulation Installation
All parts necessary to install the
insulation are shipped with the carton
containing the insulation.
1. Wrap insulation blanket around
cast iron block with the cutout facing
to the front.
2. Secure insulation blanket with
supplied spring clips.
5671 044 v1.0
2.
1.
Fig. 8
To Next Page
