What does Fault code 30 mean on a Viessmann Boiler?
If your Viessmann Boiler displays Fault code 30, this indicates a short circuit in the boiler water temperature sensor. You should check the boiler water temperature sensor.
What to do if my Viessmann Vitodens 100-W Boiler starts a self-diagnostic check when turned on?
When the Viessmann Boiler is initially turned on, it starts a self-diagnostic check. Wait until the temperature display stabilizes and the boiler displays the actual temperature.
What to do if my Viessmann Boiler shows fault F4?
If your Viessmann Boiler displays fault code F4, there are several potential solutions: * Check the ignition module connection. * Check the gas train (control voltage 230 V) and the gas supply pressure. * Check the ionisation current, the electrode adjustment, and the gas line for air-locks.
What to check if the gas train opens in a Viessmann Vitodens 100-W?
If the gas train opens in your Viessmann Boiler, which is related to fault F4, you should check the gas train itself for the correct control voltage (230 V) and also verify the gas supply pressure.
What does Fault code 38 mean on a Viessmann Vitodens 100-W Boiler?
If your Viessmann Boiler displays Fault code 38, this indicates a break in the boiler water temperature sensor. You should check the boiler water temperature sensor.
How to solve control unit issues with no increase set value in Viessmann Vitodens 100-W Boiler?
If the control unit of your Viessmann Boiler is not increasing the set value, increase the set value and ensure heat is being drawn off.
What to do if Viessmann Vitodens 100-W shows fault F4 (Check gas train)?
If your Viessmann Boiler displays fault F4 related to the gas train, you should check the gas train, ensuring the control voltage is at 230V. Also, verify the gas supply pressure.
What to do if Viessmann Vitodens 100-W shows fault F4 (Measure ionisation current)?
If you're seeing fault F4 on your Viessmann Boiler related to measuring ionization current, you should measure the ionization current. Also, check the electrode adjustment and inspect the gas line for any airlocks.
What to do if Viessmann Vitodens 100-W Boiler fan doesn't start after 1 minute?
If the fan in your Viessmann Boiler fails to start after approximately 1 minute, it may be due to fault F9. You should check the fan itself, the fan connecting cables, the power supply to the fan, and the fan control system.
What does fault code 10 mean on my Viessmann Vitodens 100-W?
If your Viessmann Boiler displays fault code 10, it indicates a short circuit in the outside temperature sensor. Check the outside temperature sensor and lead.
General| Type | Wall-mounted gas condensing boiler |
|---|---|
| Installation | Wall-mounted |
| Fuel Type | Natural gas or LPG |
| Heat Exchanger Material | Stainless steel |
| Efficiency | Up to 98% |
| Warranty | Up to 10 years (depending on installation and usage) |
| Control | Vitotronic control unit with LCD display |
| Dimensions | 700mm x 400mm x 350mm |
| Heating Output | 1.9 to 35 kW |
Explains warning symbols and provides initial safety advice.
Actions for gas or flue gas leaks to prevent hazards.
Procedures for system isolation and warnings about component use.
Vitodens 100-W models, features, and technical data.
Physical dimensions, installation clearances, and flue system requirements.
Hydraulic circuit diagrams and electrical supply requirements.
Boiler position, flue terminal location, and connection preparation.
Steps for mounting boiler and making gas, heating, condensate connections.
Steps for installing external wall and vertical roof flue terminals.
Electrical connections, testing, and boiler water temperature settings.
Advice on operation, controls, and maintenance for the user.
Servicing recommendations and steps for front panel removal.
Procedures for burner removal, inspection, and electrode checks.
Heating surface cleaning and condensate drain/siphon checks.
Boiler start-up after service and final checks.
Flowcharts and tables for identifying and resolving faults.
Steps for checking and repairing sensors and limiters.
Steps to check the fuse (F1) in the control unit.
Diagrams showing electrical connections and component layouts.
Instructions for identifying and ordering spare parts with diagrams.
Checklist for boiler commissioning, including system and control checks.
Section for recording service history and engineer details.
Declaration of conformity with standards and directives.
