3
Ventilation Requirements for enclosure locating
To allow heat to disperse, leave space between surrounding objects as shown in the diagram below.
100 mm 100 mm
100 mm
100 mm
1.5. Using of Remote sensor and power indicator
1. Pull down the lens to have better remote control performance and easy to observe the light information of
power status.
2. Push up the lens before mounting the display for video wall application.
3. Pull/Push the lens until hearing the click sound.
Push right to collapse the lens Push left to extend the lens
