ViewSonic CDE4320 User Manual

42
Optional function
Get Function Length ID Command
Type
Command Response Range Comments
(ASCII) Code
(ASCII)
Code
(Hex)
(Three ASCII
bytes)
Get-Contrast 8 g a 61 000 ~ 100
Get-Sharp-
ness
8 g c 63 000 ~ 100
Get-Color 8 g d 64 000 ~ 100
Get-Tint 8 g e 65 000 ~ 100
Get-Backlight
On_O󰀨
*3.2.3
8 g h 68 000: O󰀨
001: On
Get-Date:
Year
8 g 2 32 Y00~Y00 Last 2 digits
(20)17~(20)99
Get-Date:
Month
8 g 2 32 M00~M00 2 digits
Get-Date:
Day
8 g 2 32 D00~M00 2 digits
Get-Time:
Hour
8 g 3 33 H00~H00 24-hr format. 2 digits
Get-Time:
Min
8 g 3 33 M00~M00 2 digits
Get-Time:
Sec
8 g 3 33 S00~S00 2 digits
11.3.3. Remote Control Pass-through mode
When the PC sets the TV/DS to Remote Control Pass through mode, the TV/DS will send a 7-byte packet
(followed by “CR”) in response to RCU button activation. Note, that in this mode the RCU shall have no
e󰀨ect on the TV/DS function. For example: “Volume+” will not change the volume in the LCD but only sends
“Volume+” code to PC over the RS232 port.
IR Pass Through-Function format
Reply: (Command Type=”p”)
Name Length ID
Command
Type
RCU Code1
(MSB)
RCU Code2
(LSB)
CR
Byte Count 1 Byte 2 Byte 1 Byte 1 Byte 1 Byte 1 Byte
Bytes order 1 2~3 4 5 6 7
Example1: Remote Control pass-through when “VOL+” key is pressed for TV-05 Send (Hex Format)
Name Length ID
Command
Type
Command Value1 CR
Hex 0x36
0x30
0x35
0x70 0x31 0x30 0x0D
