ViewSonic CDE5010 User Manual

38
OSD Transparency
Adjust OSD transparency.
• {O󰀨} - Transparency o󰀨.
• {1-100} - Transparency level 1-100.
Power Save
Mode 1 [TCP o󰀨, WOL on, auto o󰀨]
Mode 2 [TCP o󰀨, WOL on, auto on/o󰀨]
Mode 3 [TCP on, WOL o󰀨, auto on/o󰀨]
Mode 4 [TCP on, WOL o󰀨, no auto on/o󰀨]
Power save modes
Mode 1: DC o󰀨 -> Power o󰀨. LED: Red.
Power Save -> Power o󰀨, LED: Red
Mode 2: DC o󰀨 -> Power o󰀨, LED: Red.
Power Save -> Power Saving.
LED: Orange. Can be wake up.
Mode 3: DC o󰀨 -> Back light o󰀨, LED: Red
Power Save -> Back light o󰀨,
LED: Orange. Can be wake up.
Mode 4: DC o󰀨 -> Back light o󰀨, LED: Red
Power Save -> Will not enter power save mode. show “no signal” only.
RCU Power
Button Off
No Signal WoL
Android
(ARM)
Mode 1 [TCP off,
WOL on, auto off]
DC OFF DC OFF V ARM OFF
Mode 2 [TCP off,
WOL on, auto on/
off] (gary out)
DC OFF
When signal is
back, system wake
up
V ARM OFF
Mode 3 [TCP off,
WOL off, auto on/
off]
Backlight OFF Backlight OFF X ARM OFF
Mode 4 [TCP off,
WOL off, no auto
on/off]
Backlight OFF
Backlight ON,
show no signal
X ARM OFF
* This product does not suppor t Mode 2
Following table is the action for Android board with di󰀨erent power mode.
DC o󰀨/on: press power button by RC
Power mode in OSD Mode 1/2 Mode 3/4
DC off shutdown
1. The cur rent source APK
(such as MediaPlayer,
Broswer, PDF or Smar
tCMS) will be closed.
2. Android system will go to
the default black launcher.
DC on Boot up 1. Android system reboots
