ViewSonic IFP50 Series User Manual

92
B. Optional function
Get Function Length ID Command
Type
Command Response Range Comments
(ASCII) Code (ASCII) Code (Hex) (Three ASCII bytes)
Get-Contrast 8 g a 61 000 ~ 100
Get-Sharp-
ness
8 g c 63 000 ~ 100
Get-Color 8 g d 64 000 ~ 100
Get-Tint 8 g e 65 000 ~ 100
Get-PIP
mode
8 g t 74 000: OFF
001: PIP (POP)
002: PBP
Get-PIP input 8 g u 75 000 ~ See Set-input select
Get-Tiling
Mode
8 g v 76 000: OFF
001: ON
(for Video wall)
Get-Tiling
Compensa-
tion
8 g w 77 000: OFF
001: ON
(for Video wall)
Bezel width compen-
sation
Get-Tiling H
by V monitors
8 g x 78 01x~09x: H moni-
tors
0x1~0x9: V moni-
tors
(for Video wall)
1. 2nd digital for H
monitors
2. 3rd digital for V
monitors
Get-Tiling
position
8 g y 79 000: OFF
001~025
(for Video wall)
Copy the screen of
Position# to identified
display
Get-Date:
Year
8 g 2 32 Y00~Y00 Last 2 digits
(20)17~(20)99
Get-Date:
Month
8 g 2 32 M00~M00 2 digits
Get-Date:
Day
8 g 2 32 D00~M00 2 digits
Get-Time:
Hour
8 g 3 33 H00~H00 24-hr format. 2 digits
Get-Time:
Min
8 g 3 33 M00~M00 2 digits
Get-Time:
Sec
8 g 3 33 S00~S00 2 digits
Get-RS232
version
8 g 6 36 001~ Version 0.0.1~9.9.9
NOTE:
1. Get Date example
Assumed the current date of display#01 as below
Date: 2017-3/15
Send: 0x 38 30 31 67 32 59 30 30 0D (Get Date:Year)
Reply: 0x 38 30 31 72 32 59 31 37 0D (“Y17”)
