83
Reply (Hex Format)
Name Length ID Command
Type
CR
Hex
0x34 0x30
0x32
0x2D 0x0D
Set-function table
A. Basic function
Set
Function
Length ID Command Command Value Range Comments
Type
(ASCII)
Code (ASCII) Code (Hex) (Three ASCII bytes)
Power on/ off
(standby)
8 s ! 21 000: STBY
001: ON
The Power-on via LAN
control may works only
under specific mode.
To see display UG for
details. *3.1.1
Input Select 8 s “ 22 000: TV
001: AV
002: S-Video
003: YPbPr
004: HDMI1
014: HDMI2
024: HDMI3
034: HDMI4
005: DVI
006: VGA1
016: VGA2
026: VGA3
007: Slot-in PC
(OPS/SDM)/HDBT
008: Internal
memory
009: DP
00A: Embedded/
Main (Android)
1. No need for USB
2. For the case of two
more same sources, the
2nd digital is used to
indicate the extension.
3. The HEX of 00A is 30
30 41.
Brightness 8 s $ 24 000 ~ 100
900: Bright down
(-1)
901: Bright up (+1)
*3.1.1
Power lock 8 s 4 34 000: Unlock
001: Lock
*See note in details
Volume 8 s 5 35 000 ~ 100
900: Volume
down(-1)
901:Volume up(+1)
Mute 8 s 6 36 000: OFF
001: ON (mute)
Button lock 8 s 8 38 000: Unlock
001: Lock
*See note in details
Menu lock 8 s > 000: Unlock
001: Lock
*See note in details
