Page #6 background imageLoading...
Page #6 background image
Using the Monitor
Setting the Timing Mode
Setting the timing mode is important for maximizing the quality of the
screen image and minimizing eye strain. The timing mode consists of the
resolution (example 1280 x 1024) and refresh rate (or vertical frequency;
example 75 Hz). After setting the timing mode, use the OnView
®
controls
to adjust the screen image.
The recommended timing mode for this monitor is:
VESA 1600 x 1200 @ 85 Hz.
To set the Timing Mode:
1 Set the resolution: Right-click on the Windows
®
desktop > Properties >
Settings > Desktop Area (Screen Area for Windows 95 and newer) > set the
resolution.
2 Set the refresh rate: See your graphic card's user guide for instructions.
NOTE: To minimize the adjustments required for an optimal screen image,
select a timing mode from the Preset Timing Modes table below.
WA R N I N G : Do NOT set the graphics card in your computer to exceed the
maximum refresh rates; doing so may result in permanent damage to your
monitor.
(NI = Non Interlaced)
Preset Timing Modes
VGA 640 x480@60Hz
VGA 720 x 400 @ 70 Hz
VESA 800 x 600 @ 85 Hz
VESA 1024 x 768 @ 75 Hz
VESA 1024 x 768 @ 85 Hz
VESA 1280 x 1024 @ 75 Hz
VESA 1280 x 1024 @ 85 Hz
VESA 1600 x 1200 @ 75 Hz
VESA 1600 x 1200 @ 85 Hz
VESA (GTF) 2048 x 1536 @ 60 Hz
Macintosh 1152 x 870 @ 75 Hz
Timing Modes with Maximum Refresh Rates
2048 x 1536 NI @ 68 Hz
1920 x 1440 NI @ 73 Hz
1600 x 1200 NI @ 87 Hz
1280 x 1024 NI @ 101 Hz
1152 x 864 NI @ 118 Hz
1024 x 768 NI @ 132 Hz
800 x 600 NI @ 160Hz
640 x 480 NI @ 160Hz
ViewSonic P220f 5

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ViewSonic P220f and is the answer not in the manual?

ViewSonic P220f Specifications

General IconGeneral
Type22\
Pixel pitch0.24 mm
Display diagonal22 \
Vertical scan range50 - 160 Hz
Horizontal scan range30 - 110 kHz
Viewable size, vertical300 mm
Viewable size, horizontal400 mm
Audio systemNo
Video inBandwidth - 266MHz (typical)
I/O portsSignal - High-density 15 pin mini D-sub Power - 3-pin plug (IEC 320)
Mounting interfacePlug & Play
Maximum resolution2048 x 1536 pixels
Operating temperature (T-T)0 - 40 °C
Operating relative humidity (H-H)5 - 95 %
CertificationTCO'03, TÜV/GS, TÜV/ERGO, ISO9241-3, ISO9241-7, ISO9241-8, Energy 2000, MPR-II, CE, CB, FCC-B, UL, CSA, DHHS, DOC-B, NEMKO, DEMKO, SEMKO, FIMKO, B-Mark, PCT, SASO, CCIB, C-Tick, S-Mark, NOM, VCCI, IRAM, ICE5003, CCEE, EMC, EMI-B
Power sourceAC 100-240V, 50/60 Hz (auto switch)
Power managementEnergy Star, VESA DPMS, TCO'03 Energy 2000
Power consumption (typical)125 W
Mac compatibilityYes
Compatible productsPC compatible from VGA up to 2048 x 1536. Power Mac compatible from 640 x 480 to 2048 x 1536. Other - Most workstations
Weight and Dimensions IconWeight and Dimensions
Weight31000 g
Dimensions (WxDxH)500 x 511.5 x 505 mm
