ViewSonic P220f User Manual

Other Information
1
Macintosh models prior to G3 require a Macintosh adapter. To order a Macintosh adapter, contact
ViewSonic Customer Support. You will need to provide serial number of the product.
2
Warning: Do NOT set the graphics card in your computer to exceed these Maximum Refresh Rates;
doing so could result in permanent damage to the monitor.
Specifications
CRT Ty p e
Phosphor
Glass surface
22” (20.0” viewable diagonal area),
0.24 mm aperture grill pitch,
90
o
deflection
RGB, medium-short persistence
Anti-reflection, anti-static coating
Standard light transmission rate = 38.4%
Input Signal Video
Sync
RGB Analog (0.7 Vp-p, 75 Ohms)
f
H
: 30-110 kHz, f
v
: 50-160Hz
HV Separate (TTL), Composite, Sync on Green
Compatibility PC
Macintosh
1
VGA up to 2048 x 1536
Power Macintosh (may require Macintosh adapter)
Timing Modes with
Maximum
Refresh
Rates
2
1280 x 1024 NI @ 101 Hz
1920 x 1440 NI @ 73 Hz
1152 x 864 NI @ 118 Hz
1856 x 1392 NI @ 75 Hz
1024 x 768 NI @ 132 Hz
1792 x 1344 NI @ 78 Hz
800 x 600 NI @ 160Hz
1600 x 1200 NI @ 87 Hz
640 x 480 NI @ 160H
Power Voltage AC 90-264V (auto switch) 50/60 Hz
Display Area Default
Full scan
396 mm (H) x 297 mm (V) (Typical)
400 mm (H) x 300 mm (V) (Depends on signal timing)
Operating
Conditions
Temperature
Humidity
Altitude
32°Fto104°F(0°Cto+40°C)
5% to 95% (no condensation)
To 10,000 feet
Storage Conditions Temperature
Humidity
Altitude
-40°Fto+140°F(-40°Cto+60°C)
5% to 95% (no condensation)
To 40,000 feet
Dimensions Physical
(monitor)
500 mm (W) x 505 mm (H) x 511.5 mm (D)
19.7” (W) x 19.9” (H) x 20.2”(D)
Weight Net 31.0 kg (68.4 lb.) (monitor only)
Regulations UL1950, cUL, DHHS, FCC, ICES-003, Class-B, (EPA) Energy Star, CE, CB,
PCBC, TUV/GS, VCCI, BSMI, C-Tick, CCC, TUV/Ergo, NEMKO, SEMKO,
DEMKO, FIMKO, GOST-R, PSB, TCO95
Power Saving
Modes
On
DPMS
TM
Standby
DPMS
TM
Suspend
DPMS
TM
Off
< 170W NORMAL (Green LED)
< 15W (Orange LED)
< 15W (Orange LED)
< 5W (Flashing Orange LED)
2048 x1536 NI @ 68 Hz
ViewSonic P220f 12

ViewSonic P220f Specifications

General

Type	22\
Pixel pitch	0.24 mm
Display diagonal	22 \
Vertical scan range	50 - 160 Hz
Horizontal scan range	30 - 110 kHz
Viewable size, vertical	300 mm
Viewable size, horizontal	400 mm
Audio system	No
Video in	Bandwidth - 266MHz (typical)
I/O ports	Signal - High-density 15 pin mini D-sub Power - 3-pin plug (IEC 320)
Mounting interface	Plug & Play
Maximum resolution	2048 x 1536 pixels
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	TCO'03, TÜV/GS, TÜV/ERGO, ISO9241-3, ISO9241-7, ISO9241-8, Energy 2000, MPR-II, CE, CB, FCC-B, UL, CSA, DHHS, DOC-B, NEMKO, DEMKO, SEMKO, FIMKO, B-Mark, PCT, SASO, CCIB, C-Tick, S-Mark, NOM, VCCI, IRAM, ICE5003, CCEE, EMC, EMI-B
Power source	AC 100-240V, 50/60 Hz (auto switch)
Power management	Energy Star, VESA DPMS, TCO'03 Energy 2000
Power consumption (typical)	125 W
Mac compatibility	Yes
Compatible products	PC compatible from VGA up to 2048 x 1536. Power Mac compatible from 640 x 480 to 2048 x 1536. Other - Most workstations

Weight and Dimensions

Weight	31000 g
Dimensions (WxDxH)	500 x 511.5 x 505 mm
