ViewSonic P220f User Manual

Adjusting the Screen Image
Beginning with the Main Menu shown below, use the buttons on the front
control panel to adjust the OnView
®
controls which display on the screen. The
OnView controls are explained in the four steps at the top of the next page and
are further explained on pages 8-10.
IMPORTANT: The monitor should be warmed up for 30 minutes prior to
making any adjustments.
Main Menu with OnView controls
ViewSonic P220f 7
Power Light
Power On/Off
Displays control screen for
highlighted control (or pair
of controls). Also, toggles
between pairs of controls on
some control screens.
Displays Main Menu;
also saves changes/
exits Main Menu.
Scrolls through menu
options and adjusts
the displayed control.
Front Control Panel
Zoom expands and contracts the entire screen image

ViewSonic P220f Specifications

General

Type	22\
Pixel pitch	0.24 mm
Display diagonal	22 \
Vertical scan range	50 - 160 Hz
Horizontal scan range	30 - 110 kHz
Viewable size, vertical	300 mm
Viewable size, horizontal	400 mm
Audio system	No
Video in	Bandwidth - 266MHz (typical)
I/O ports	Signal - High-density 15 pin mini D-sub Power - 3-pin plug (IEC 320)
Mounting interface	Plug & Play
Maximum resolution	2048 x 1536 pixels
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Certification	TCO'03, TÜV/GS, TÜV/ERGO, ISO9241-3, ISO9241-7, ISO9241-8, Energy 2000, MPR-II, CE, CB, FCC-B, UL, CSA, DHHS, DOC-B, NEMKO, DEMKO, SEMKO, FIMKO, B-Mark, PCT, SASO, CCIB, C-Tick, S-Mark, NOM, VCCI, IRAM, ICE5003, CCEE, EMC, EMI-B
Power source	AC 100-240V, 50/60 Hz (auto switch)
Power management	Energy Star, VESA DPMS, TCO'03 Energy 2000
Power consumption (typical)	125 W
Mac compatibility	Yes
Compatible products	PC compatible from VGA up to 2048 x 1536. Power Mac compatible from 640 x 480 to 2048 x 1536. Other - Most workstations

Weight and Dimensions

Weight	31000 g
Dimensions (WxDxH)	500 x 511.5 x 505 mm
