ViewSonic PJD5122 Service Manual

Appendix 1 -- Screw List /Torque
Model name : PJD5122/5211/5152/5221 (MD)
Screw P/N Description Torque
Q'ty
N
o.
Part name Type Head
Lengt
h
Surfac
e
(kgf-c
m)
Where use
Unit
Q’ty
BKT MB == LC 3
1
8F.VG564.8R0
SCRW TAP PH W/F
M3*8L NI D-PT
TAP
(DELT
A)
PHW 8 NI 7~8
BKT BLOWER==LC 2
5
POWER==LC 1
LAMP BOX==LC 2
ENGINE==LC 3
CASE OUTLET===SPEAKER
4
2
8F.VA564.7R0
SCRW TAP PAN
M3*7L NI D-PT
TAP
(DELT
A)
PH
7
NI 6~7
UC==LC 5
15
MB BKT==ENGINE HSG 1
BKT BLOWER==NOZZLE 1
MB==MB SHIELDING 4
3
8F.1D224.5R0
SCRW MACH
PAN EXT-
TOO M3*5L
ZN
MACH PH 6 ZINC 4~5
BALLAST===LC 2
8
M3
4
8F.1A524.6R0
SCRW MACH
M3*6L NI
MACH PH 6 NI 4~5 DOOR==LC 2 2
GROUNDING==MB BKT 1
M4 5
8F.1D526.6R0
SCRW MACH
PAN EXT-
TOO M4*6L
NI
MACH PAN 8 NI 6~7
CEILING MOUNT LC 3
4
SUM= 34
STAND OFF
Screw P/N Description Torque
Q'ty
N
o.
Part name Type Head
Lengt
h
Surfac
e
(kgf-cm)
Where use
Unit
Q’ty
#4-
40
6
8F.00590.120
STAND OFF
XH4#-40X4+8 NI
MACH HEX 6 NI 5~6 MB=REAR COVER 6 6
Nut
Screw P/N Description Torque
Q'ty
N
o.
Part name Type Head
Lengt
h
Surfac
e
(kgf-cm)
Where use
Unit
Q’ty
7 8G.00020.423 NUT HEX 2.3 NI 3.5+/-0.5 Nut & Foot Rear 1 1
Confidential - Do Not Copy
PJD5122
ViewSonic Corporation
90

ViewSonic PJD5122 Specifications

General

Projection distance	1.2 - 11.3 m
Vertical scan range	48 - 120 Hz
Horizontal scan range	31 - 100 kHz
Projection technology	DLP
Contrast ratio (typical)	2000:1
Screen size compatibility	30 - 300 \
Projector native resolution	SVGA (800x600)
Keystone correction, vertical	± 40 °
Resolution	1280 x 1024 pixels
Aspect ratio	4:3, 16:9
RS-232 ports	1
Weight (imperial)	5.1 lbs
Dimensions (WxDxH)	264 x 225 x 96.4 mm
Power requirements	100 - 240 V, 50/60 Hz
Connectivity technology	Wired
Lamp power	220 W
Light source type	Lamp
Service life of light source	4000 h
Service life of light source (economic mode)	6000 h
Focus	Manual
Focal length range	- mm
Full HD	No
HD-Ready	Yes
Analog signal format system	SECAM
RMS rated power	5 W
Audio (L/R) in	0
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Component video (YPbPr/YCbCr) in	2
Cables included	VGA
Noise level	32 dB
Certification	CB, RoHS, WEEE, UL/cUL, FCC-B, ICES-003, IRAM, NOM, PSB, C-tick, EK, CE, TUV/GS, GOST-R, SASO UKrSEPRO, CCC
Noise level (economic mode)	26 dB
Power consumption (standby)	1 W
Power consumption (typical)	280 W
Operating altitude	1.8 - 3048 m
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Market positioning	Presentation

Weight and Dimensions

Weight	2300 g
