Installaon

There are two installaon methods: Wall-Mounted and Floor Stand.

Before Installing

Maintain an adequate air gap between the back of the display and any wall

for proper venlaon.

Ensure there is no direct airflow from air conditioning or heating vents

blowing on the display.

Avoid installing the display in places with high humidity.

Due to high power usage, always use power cords specically designed for

this product.

Wall Mounng

Installing the Upper and Lower Wall Mount Brackets

1490

1400 mm

1000 mm

600 mm

200 mm

7 mm

12 mm

15 mm

1. Ensure the wall area and size is an appropriate installaon site.

NOTE: The height of the Upper Wall Mount Brackets must not be less than

90.55" (2.3 meters) from the ground.

2. Using the Wall Mount Bracket (pictured above) as a guide, mark each of the eight

(8) holes and pre-drill each.

3. Install the rst Upper Wall Mount Bracket with the provided screws (M6x50mm

Expansion for masonry; TA6x30mm for load bearing wood).

4. Repeat Step 2, ensuring the second Upper Wall Mount Bracket is level with the

rst upper bracket.
