ViewSonic Corporation Confidential - Do Not Copy VX2235wm-3
20
5. Adjustment Procedure
1. Function Test
1.1 Product
- 22” LCD Monitor
1.2 Test Equipment
- Color Video Signal & Pattern (or PC with WSXGA+ resolution and a sound card)
1.3 Test Condition
Before function test and alignment, each LCD Monitor should be run-in and warmed up for at least
30 minutes with the following conditions:
(a) In room temperature,
(b) With full-white screen, RGB, and Black
(c) With cycled display modes,
640*480 (H=43.27kHz, V=85Hz)
800*600 (H=53.7kHz, V=85Hz)
1024*768 (H=68.67kHz, V=85Hz)
1680*1050 (H=64.7kHz, V=60Hz)
1.4 Test Display Modes & Pattern
1.4.1 Compatible Modes
Analog Digital
1. 640 x 350 @ 70Hz, 31.5kHz
2. 640 x 400 @ 60Hz, 31.5kHz
3. 640 x 400 @ 70Hz, 31.5kHz
4. 640 x 480 @ 50Hz, 24.7kHz
5. 640 x 480 @ 60Hz, 31.5kHz
6. 640 x 480 @ 67Hz, 35.0kHz
7. 640 x 480 @ 72Hz, 37.9kHz
8. 640 x 480 @ 75Hz, 37.5kHz
9. 640 x 480 @ 85Hz, 43.27kHz
10. 720 x 400 @ 70Hz, 31.5kHz
11. 720 x 480 @ 60Hz, 31.5kHz
12. 720 x 576 @ 50Hz, 31.3kHz
13. 800 x 600 @ 50Hz, 24.7kHz
14. 800 x 600 @ 56Hz, 35.1kHz
15. 800 x 600 @ 60Hz, 37.9kHz
16. 800 x 600 @ 70Hz, 43 kHz
17. 800 x 600 @ 72Hz, 48.1kHz
18. 800 x 600 @ 75Hz, 46.9kHz
19. 800 x 600 @ 85Hz, 53.7kHz
20. 832 x 624 @ 75Hz, 49.7kHz
21. 1024 x 768 @ 50Hz, 39.6kHz
22. 1024 x 768 @ 60Hz, 48.4kHz
23. 1024 x 768 @ 70Hz, 56.5kHz
24. 1024 x 768 @ 72Hz, 58.1kHz
25. 1024 x 768 @ 75Hz, 60 kHz
26. 1024 x 768 @ 85Hz, 68.7 kHz
27. 1152 x 864 @ 75Hz, 67.5 kHz
28. 1152 x 870 @ 75Hz, 68.7 kHz
640 x 350 @ 70Hz, 31.5kHz
640 x 400 @ 60Hz, 31.5kHz
640 x 400 @ 70Hz, 31.5kHz
640 x 480 @ 50Hz, 24.7kHz
640 x 480 @ 60Hz, 31.5kHz
640 x 480 @ 67Hz, 35.0kHz
640 x 480 @ 72Hz, 37.9kHz
640 x 480 @ 75Hz, 37.5kHz
640 x 480 @ 85Hz, 43.27kHz
720 x 400 @ 70Hz, 31.5kHz
720 x 480 @ 60Hz, 31.5kHz
720 x 576 @ 50Hz, 31.3kHz
800 x 600 @ 50Hz, 24.7kHz
800 x 600 @ 56Hz, 35.1kHz
800 x 600 @ 60Hz, 37.9kHz
800 x 600 @ 70Hz, 43 kHz
800 x 600 @ 72Hz, 48.1kHz
800 x 600 @ 75Hz, 46.9kHz
800 x 600 @ 85Hz, 53.7kHz
832 x 624 @ 75Hz, 49.7kHz
1024 x 768 @ 50Hz, 39.6kHz
1024 x 768 @ 60Hz, 48.4kHz
1024 x 768 @ 70Hz, 56.5kHz
1024 x 768 @ 72Hz, 58.1kHz
1024 x 768 @ 75Hz, 60 kHz
1024 x 768 @ 85Hz, 68.7 kHz
1152 x 864 @ 75Hz, 67.5 kHz
1152 x 870 @ 75Hz, 68.7 kHz
