ViewSonic Corporation Confidential - Do Not Copy VX2235wm-3
3
2. Specification
FEATURES VX2235wm-3
Size
22 " wide
Luminance (Typ)
300 cd/㎡
Contrast Ratio (Typ) 900:1
Colors 16.7 M (8bits RGB)
Response Time 5 ms(on/off)
Viewing Angle (H/V) 170 ° / 160 °
TFTLCD PANEL
1
st
AUO
M220EW01 V0
Recommend resolution 1680x1050@60Hz
Analog Yes (75ohms, 0.7/1.0 Vp-p)
Input Signal
Digital Yes
Separate Sync Yes
Composite Sync Yes
Sync Compatibility
Sync on Green Yes
PC Yes
Power Mac Yes
Compatibility
TV Box (NextVision 6) Yes
Power Voltage AC 100-240V, 50/60Hz Yes
On Mode(Typ) < 48 W
Power Consumption
Off Mode (Max) ≦1 W
Audio 2.5W / THD 10% (Max) Yes
Tilt ( 20 ° - -5 °)
Yes
Swivel No
Pivot No
Ergonomics
Height Adjust No
OSD Control [ 1 ] [ 2 ] [ ][▼] [▲] Yes
Physical (W x H x D) 528 x 483 x 244 mm
Dimension
Package (W x H x D) 575 x 535x 172mm
Physical (Net Weight) 6.8Kg / 15 lbs
Weight
Package (Gross Weight) 9.2Kg / 20.3 lbs
Temperature (℉/℃) 32℉-104 /℉ 0℃-40℃
Operating Condition
Humidity (%) 20% - 90%
Temperature (℉/℃) -4℉-140 /℉ -20℃- 60℃
Storage Condition
Humidity (%) 10% - 90%
Regulation
Global: CB, MPR II,WEEE,ROHS , ISO13406-2
VSA:UL, cUL, FCC-B, TUV-S, NOM, Energy Star
VSE:TUV/ERGO(covers ISO13406-2&MPR II),CE
GOST-R+Hygienic ,SASO , ENERGY
VSI: BSMI, CCC, PSB, C-TICK, MIC
VSCN:CCC
4-1 GENERAL specification
Test Resolution & Frequency 1680x1050 @ 60Hz
Test Image Size Full Size
Contrast and Brightness Controls
Factory Default:
Contrast = 70%, Brightness = 100%
4-2 VIDEO INTERFACE
Analog Input Connector DB-15 (Analog), refer the appendix A
Digital Input Connector DVI-D(Digital), refer the appendix B
Default Input Connector Defaults to the first detected input
Video Cable Strain Relief Equal to twice the weight of the monitor for five minutes
Video Cable Connector DB-15 Pin out Compliant DDC 1/2B
Video Signals
1. Video RGB (Analog)
Separate, Composite, and Sync on Green
2. TMDS (Digital)
Video Impedance 75 Ohms (Analog), 100 Ohms (Digital)
Maximum PC Video Signal 950 mV with no damage to monitor
Maximum Mac Video Signal 1250 mV with no damage to monitor
