ViewSonic Model Number: VS11446
Rev: 1a
Serial No. Prefix: QCZ
Item ViewSonic P/N Ref. P/N Description Q'ty
1 N/A 2024275301P FRONT BEZEL VX2235/ABS 94HB BLACK C 1
2 N/A 2053756401P LED INDIC.-PWR VX2035/PMMA 94HB 1
3 N/A 2044270901P FUNCTION KEY VX2235 ABS 94HB BLACK C 1
4 M-SCW-0824-0285 2084730082P SCREW,BND T+ M3X8(BND T+) 2
5 M-SCW-0824-0285 2084730082P SCREW,BND T+ M3X8(BND T+) 4
6 M-SCW-0824-0285 2084730082P SCREW,BND T+ M3X8(BND T+) 1
7 N/A 2084740082P SCREW,BND T+ M4X8(BND T+) 6
8 N/A 2022270301P CABI BACK VX2235/ABS HB BLACK C+PS-7604B 1
9 M-BK-0805-0070 2071869400P BRACKET,FIX METAL PLATE 1.0MM KENSINGTON 1
10 HW-00003031 2071872900P BRACKET,FIX JT198QP SECC 0.8T WALL MOUNT 1
11 PL-00008054 2028263001P STAND VX2035/ABS 94HB BLACK C 1
12 N/A 2027267502P DUST COVER VX2035 ABS 94HB PS-7604B 1
13 N/A 2071885000P BRACKET,FIX VX2035_BASE-METAL SECC T=1MM 1
14 N/A 2083740082P SCREW,BND T+ M4*8(BND T+) 5
15 PL-PD-0714-0113 2039819301P FOOT PAD RUBBER O20*2TMM SQUARE GRAIN 5
16 N/A 2028556202P NECK VX2035/ARM-F ABS 94HB PS-7604B 1
17 N/A 2028556302P NECK VX2035/ARM-B ABS 94HB PS-7604B 1
18 M-SCW-0824-0285 2084730082P SCREW,BND T+ M3X8(BND T+) 2
19 N/A 2105252400P SPRING PLATE PB-CU T:0.2MM 1
20 M-SCW-0824-0812 2084730062P SCREW,BND T+ M3X6(BND T+) 1
21 N/A 2106659700P HINGE(RA) VX2235 HINGE -5~+15' (TL) 1
21 N/A 2106659701P HINGE(RB) VX2235 HINGE -5~+20' (HY) 1
21 N/A 2106659702P HINGE(RC) VX2235 HINGE -5'~+20' (ZJ) 1
22 M-SCW-0824-0123 2084740102P SCREW,BND T+ M4X10(BND T+) 4
23 N/A 2071983400P METAL FITTG VX2235 SECC T=0.8MM 1
24 M-SCW-0824-6715 2080002200P SCREW,SPE L355 M3x6 DH NICKEL-PLATED 4
25 M-SCW-0824-0811 2080003700P SCREW,SPE ISZZTER001A M3*6L MSWR17/FZMYI 6
26 HW-00003028 2071874300P BRACKET,FIX SECC T=0.8 VE910 ACINLET 1
27 M-SCW-0824-0811 2080003700P SCREW,SPE ISZZTER001A M3*6L MSWR17/FZMYI 2
28 N/A 2071678900P SHIELD PLATE VX2235 DUAL SPTE T=0.3MM 1
29 M-SCW-0824-6719 2082630062P SCREW M3X6 P=0.5 3
30 N/A 2071885100P BRACKET,FIX VX2235 HINGE FIX SECC T=1.0MM 1
31 M-SCW-0824-6719 2082630062P SCREW M3X6 P=0.5 4
32 M-SCW-0824-0123 2084740102P SCREW,BND T+ M4X10(BND T+) 4
33 N/A 2082630064P SCREW M3*6 P=0.5 BLACK 4
34 M-SCW-0824-0440 2085740102P SCREW,B OTW+ SCREW, B 0TW+ M4*10 6
35 N/A 2027267001P DUST COVER VX2235 ABS 94HB BLACK C (R) 1
36 N/A 2027267101P DUST COVER VX2235 ABS 94HB BLACK C (L) 1
37 N/A 2427404032P WIRE HARNESS 2+2/4P H/A 1007#24 L=250mm 1
38 N/A 2427410008P WIRE HARNESS 8/10P H/B 1007#26 L=300mm 1
39 N/A 2427409004P WIRE HARNESS 9/9P H/B 1007#26 L=130mm 1
40 N/A 2420330181P FFC CABLE 30P*P0.5*L157mm 1
41 E-00008181 2391302502P SPEAKER ASS'Y 2.5W/4ohm(L) L80*W29*H20 D.L 1
42 E-00008180 2391302501P SPEAKER ASS'Y 2.5W/4ohm(R) L80*W29*H20 D.L 1
EXPLODED PARTS LIST (VX2235wm-3)
