ViewSonic Corporation Confidential - Do Not Copy VX2235wm-3
4
Sync Signals TTL
DDC 1/2B Compliant with Revision 1.3
Sync Compatibility Separate Sync, Composite Sync, SOG
Video Compatibility
Shall be compatible with all PC type computers, Macintosh computers,
and after market video cards
Resolution Compatibility
640 x 350*, 640 x 480, 720 x 400* (640 x 400*), 800 x 600, 832 x
624, 1024 x 768, 1152 x 864, 1152 x 870, 1280 x 720, 1280 x 960,
1280 x 1024 , 1400 x 1050 , 1440 x 900 , 1600 x 1200, 1680 x 1050
* The image vertical size might not be full screen.
But the image vertical position should be at the center.
Exclusions Not compatible with interlaced video
4-3 POWER SUPPLY
Internal Power Supply Part Number: HJC- H0AU032001
INPUT VOLTAGE RANGE AC100~240 (WORLDWIDE)
Input Frequency Range 47 TO 63 HERTZ
Short Circuit Protection Output can be shorted without damage
Over Current Protection 5A TYPICAL AT 5 VDC ( Protect when short circuit )
Leakage Current 3.5mA (Max) at 264VAC / 50Hz
EFFICIENCY 80 % typical at 115VAC Full Load
75% minimum at 115VAC Full Load
Fuse Internal and not user replaceable
Power Dissipation < 48 Watts (typ)
Max Input AC Current 1.5Arms @ 90VAC , 0.75Arms@ 180VAC
INRUSH CURRENT (COLD START)
50A MAX./ 115V
AC
/ 60HZ (COLD START AT 25 ,FULL LOAD)℃
90A MAX./ 230V
AC
/ 50HZ (COLD START AT 25 ,F℃ ULL LOAD)
Power Supply Cold Start
Shall start and function properly when under full load, with all
combinations of input voltage, input frequency, and operating
temperature
Power Supply Transient Immunity
Shall be able to withstand an ANSI/IEEE C62.41-1980 6000V 200
ampere ring wave transient test with no damage
Power Supply Line Surge Immunity
Shall be able to withstand 1.5 times nominal line voltage for one cycle
with no damage
Power Supply Missing Cycle Immunity
Shall be able to function properly, without reset or visible screen
artifacts, when ½ cycle of AC power is randomly missing at nominal
input
Power Supply Acoustics
The power supply shall not produce audible noise that would be
detectable by the user. Audible shall define to be in compliance with
ISO 7779 (DIN EN27779:1991) Noise measurements of machines
acoustics. Power Switch noise shall not be considered
US Type Power Cable
Separate 3-prong NEMA 5-15P type plug. Length = 1.8m. Connects to
display.
Color = Black
European Type Power Cable
Schuko CEE7-7 type plug.
Length = 1.8m, Connects to display.
Color = Black
CCC Type Power Cable
Separate 3-prong type plug.
Length = 1.8m. Connects to display.
Color = Black
PSE Type Power Cable
Separate 2-prong NEMA 1-15P type plug. Length = 1.8m. Connects to
display.
Color = Black
Power Saving Operation(Method) VESA DPMS Signaling
Power Consumption
On Mode- W/O Audio < 43W (Typ) / 48W (Max)
On Mode- W/Audio < 50W (Typ) / 55W (Max)
Saving Mode < 2 W@230VAC 50HZ
Off Mode < 1 W @230VAC 50Hz
(DC Power Off; Meet to Energy Star Ver4.0 Tier2)
Recovery Time On Mode = N/A, Active Off < 3 sec
