ViewSonic VX2235wm-3 User Manual

ViewSonic Model Number: VS11446
Rev: 1a
Serial No. Prefix: QCZ
Item ViewSonic P/N Ref. P/N Description Location Universal number# Q'ty
1 DC-00008154 2002310604P GUARANT CARD VIEWSONIC VX2235WM-3 QSG 6P81 1
2 P-00008191 2011122301P CARTON BOX VIEWSONIC VX2235WM-3 VS11446 6P01 1
3 P-00008192 2012195500P POLYFOAM VX2235 EPS (BOTTOM) 6P20 1
4 P-00008193 2012195600P POLYFOAM VX2235 EPS (TOP) 6P21 1
5 M-MS-0808-1317 2013053000P POLYETHY BAG 90CMX75CMX0.02t PE-LD 6P60 1
6 N/A 2013054020P POLYETHY BAG 450*350MM T=0.03MM LDPE 6P75 1
7 N/A 2013228806P POLYETHY BAG 150X250X0.03T mm LDPE VSC LCD 6P85 1
8 N/A 2022270301P CABI BACK VX2235/ABS HB BLACK C+PS-7604B 2C01 1
9 N/A 2024275301P FRONT BEZEL VX2235/ABS 94HB BLACK C 1F01 1
10 N/A 2027267001P DUST COVER VX2235 ABS 94HB BLACK C (R) 6B05 1
11 N/A 2027267101P DUST COVER VX2235 ABS 94HB BLACK C (L) 6B06 1
12 N/A 2027267502P DUST COVER VX2035 ABS 94HB PS-7604B 5B02 1
13 PL-00008054 2028263001P STAND VX2035/ABS 94HB BLACK C 5B01 1
14 N/A 2028556202P NECK VX2035/ARM-F ABS 94HB PS-7604B 5B08 1
15 N/A 2028556302P NECK VX2035/ARM-B ABS 94HB PS-7604B 5B09 1
16 PL-PD-0714-0113 2039819301P FOOT PAD RUBBER O20*2TMM SQUARE GRAIN 5B05 5
17 N/A 2044270901P FUNCTION KEY VX2235 ABS 94HB BLACK C 1F03 1
18 M-MS-0808-9214 2051352100P NAME PLATE VIEWSONIC E015-006 3-BIRD LOGO 1F04 1
19 N/A 2051352800P NAME PLATE 38.00MM*5.90MM 1F05 1
20 N/A 2053756401P LED INDIC.-PWR VX2035/PMMA 94HB 1F02 1
21 N/A 2055134164P LABEL VX2235WM-3 VS11446 AUO MPRII 6P50 1
22 N/A 2055613379P LABEL VIEWSONIC CONTAINER LABEL 6P11 1/48
23 M-LB-0813-0959 2055613392P LABEL VSC HIGH VOLTAGE WARNING LABEL 6P14 1
24 N/A 2055613522P LABEL VX2235WM-3 STAND LABEL 5B50 1
25 N/A 2055613523P LABEL VIEWSONIC 5MS STICKER 6P08 1
26 N/A 2055613528P LABEL VIEWSONIC VX2235WM-3 POP LABEL 6P06 1
27 M-LB-0813-0530 2055617101P LABEL 10*20 HI-POT TESTED OK 6P13 1
28 N/A 2055632228P LABEL VX2235WM-1 VS11446 (G) AUO 6P02 1
29 N/A 2055636063P LABEL VX2235WM-3 VS11446 SMALL LABEL 6P05 1
30 N/A 2055690060P LABEL ENERGYSTAR LABEL 11X11MM NO PP 6P04 1
31 M-MS-0808-9408 2061453400P BUSHING VE710 PLUG RUBBER 2C04 4
32 N/A 2071678900P SHIELD PLATE VX2235 DUAL SPTE T=0.3MM 5F07 1
33 M-BK-0805-0070 2071869400P BRACKET,FIX METAL PLATE 1.0MM KENSINGTON 2C02 1
34 HW-00003031 2071872900P BRACKET,FIX JT198QP SECC 0.8T WALL MOUNT 2C03 1
35 HW-00003028 2071874300P BRACKET,FIX SECC T=0.8 VE910 ACINLET 5F04 1
36 N/A 2071885000P BRACKET,FIX VX2035_BASE-METAL SECC T=1MM 5B03 1
37 N/A 2071885100P BRACKET,FIX VX2235 HINGE FIX SECC T=1.0MM 5F09 1
38 N/A 2071983400P METAL FITTG VX2235 SECC T=0.8MM 5F01 1
39 N/A 2072253903P HEAT SINK JT178DP SPTE T=1MM 9H03 1
40 N/A 2072253903P HEAT SINK JT178DP SPTE T=1MM 9H04 1
41 N/A 2072259301P HEAT SINK JC186H AL6063S-T5 69.5*20*25H 9H01 1
42 N/A 2072263101P HEAT SINK AL 55L*24.5W*20HMM T=2.5 9H02 1
43 N/A 2074163001P HOLDER VX2035-DOWN/ABS 94HB PS-7604B 5B16 1
44 N/A 2074163101P HOLDER VX2035-UP/ABS 94HB PS-7604B 5B17 1
45 N/A 2080002200P SCREW,SPE L355 M3x6 DH NICKEL-PLATED 5F02 4
46 M-SCW-0824-0811 2080003700P SCREW,SPE ISZZTER001A M3*6L MSWR17/FZMYI 5F03 6
47 M-SCW-0824-0811 2080003700P SCREW,SPE ISZZTER001A M3*6L MSWR17/FZMYI 5F05 2
48 N/A 2082630062P SCREW M3X6 P=0.5 5F08 3
49 N/A 2082630062P SCREW M3X6 P=0.5 5F10 4
50 N/A 2082630064P SCREW M3*6 P=0.5 BLACK 6B02 4
51 N/A 2083740082P SCREW,BND T+ M4*8(BND T+) 5B04 5
52 M-SCW-0824-0812 2084730062P SCREW,BND T+ M3X6(BND T+) 5B12 1
53 M-SCW-0824-0285 2084730082P SCREW,BND T+ M3X8(BND T+) 9S01 1
54 M-SCW-0824-0285 2084730082P SCREW,BND T+ M3X8(BND T+) 9S02 1
55 M-SCW-0824-0285 2084730082P SCREW,BND T+ M3X8(BND T+) 9S03 1
56 M-SCW-0824-0285 2084730082P SCREW,BND T+ M3X8(BND T+) 1F06 2
57 M-SCW-0824-0285 2084730082P SCREW,BND T+ M3X8(BND T+) 1F07 4
58 M-SCW-0824-0285 2084730082P SCREW,BND T+ M3X8(BND T+) 1F08 1
59 M-SCW-0824-0285 2084730082P SCREW,BND T+ M3X8(BND T+) 5B10 2
60 N/A 2084740082P SCREW,BND T+ M4X8(BND T+) 1F09 6
61 M-SCW-0824-0123 2084740102P SCREW,BND T+ M4X10(BND T+) 5B15 4
62 M-SCW-0824-0123 2084740102P SCREW,BND T+ M4X10(BND T+) 6B01 4
63 M-SCW-0824-0440 2085740102P SCREW,B OTW+ SCREW, B 0TW+ M4*10 6B03 6
64 M-00003554 2097400301P EYELET BSS3-1/2H T=0.25 SN 3uM PG85 1
65 M-00003554 2097400301P EYELET BSS3-1/2H T=0.25 SN 3uM PG86 1
66 M-00003554 2097400301P EYELET BSS3-1/2H T=0.25 SN 3uM PG87 1
67 N/A 2105251400P SPRING PLATE SPTE T=0.4MM (GROUND PLATE) 9H10 3
68 N/A 2105252400P SPRING PLATE PB-CU T:0.2MM 5B11 1
69 N/A 2106659700P HINGE VX2235 HINGE -5~+15' (TL) 5B13 RA 1
70 N/A 2106659701P HINGE VX2235 HINGE -5~+20' (HY) 5B13 RB 1
71 N/A 2106659702P HINGE VX2235 HINGE -5'~+20' (ZJ) 5B13 RC 1
72 N/A 2202135400P PC BOARD JT229ZP6MR P/B FR1 196*146 U801 1
73 N/A 2202526300P PCB MULTILAYER VG2030VW-1 M/B FR4*2 90*100 U101 1
74 N/A 2202526900P PCB MULTILAYER Q20WB K/B FR4*2 185*14.5 U701 1
75 E-00006218 2212011500P LCD PANEL M220EW01 V.0 AUO V901 1
76 E-FS-0410-0009 2213125207P FUSE 21502.5(2.5A) LITTEL F801 RA 1
77 E-FS-0410-0102 2213125211P FUSE FUSE 2.5A/250V SG501302.5 PICO F801 RB 1
78 E-TH-0416-0042 2229201212P THERMISTOR,PTH SCK-103 THINKING R802 1
79 E-R-0405-1757 2233410195P RES,CBN 1/4 S RD 1/4WS 100 ohm J T52 R831 1
BOM LIST (VX2235wm-3)
ViewSonic Corporation Confidential - Do Not Copy VX2235wm-3
57
