VIGAS 40 Lambda Control - OPERATION WITH LAMBDA CONTROL

Gasifying boiler VIGAS
Choose one option
+60 To start discharge fan for 60 s (use with flame up phase)
ON Switch on

Cancel display driver
▲
Change indicated figure
Select „+60“ new graphic drive will appear. Running time of discharge
fan is located in the left upper corner of the display.
+60
You can add extra 60 s - maximum 300 s
ON
Switch on
0
Discharge fan switched-off
▲
Change indicated figure
4.1.5 Boiler shut down (automatic)
5. VIGAS BOILER IN CONFIGURATION WITH DISCHARGE
FAN (without lambda sensor)
The advantage of discharge fan installation is increased comfort during boiler flame up and fuel addition.
Discharge fan significantly helps to reduce smoke in area during fuel feed. In flame-up phase helps to
create quickly heated fuel layer.
5.1 VIGAS BOILER CONTROL
5.1.1 Boiler activation
5.1.2 Boiler active – heating phase
11
When exhaust gas temperature drops under the set up temperature (
end),the boiler is automatically switched-off. Sign „END“ will be
indicated on the display. By pressing 2 times „ENTER“ button boiler will
start working again.
If the boiler is in switch-off phase, with symbol „OFF“ on the display, to
retrieve start press short middle „ENTER button.
By pressing „ON“ discharge fan will be switched-off and boiler will go to
flame-up phase. In flame up phase boiler exhaust gas temperature is
lower then set up minimum exhaust gas temperature. Minimum and
maximum temperature can be modified in boiler parameters set up.
Minimum standard exhaust gas temperature is set up to 50 °C and
maximum set up temperature is at 220 °C. The pump works in pulsating
wave during flame-up, depending on the boiler water temperature.
