Viking DEVDSC305 Installation Guide

BASIC SPECIFICATIONS VGIC
Description 30” W. Models 36” W. Models 48” W. Models
Overall width 29 7/8” (75.9 cm) 35 7/8” (91.1 cm) 47 7/8” (121.6 cm)
Overall height Base Height Open Top Burners Sealed Top Burners
To top of: grate support - burner grate -
Min. 35 7/8 “ (91.1 cm) 37 3/8” (94.9 cm)
Max. 37 5/8” (95.6 cm) 39 1/8” (99.4 cm)
Legs adjust 1 3/4” (4.5 cm) 1 3/4” (4.5 cm)
Additions to Base Height
To top of spider grate - add 1 1/8” (2.9 cm) To top of 10” backguard - add 10” (25.4 cm)
To top of island trim - add 1 1/4” (3.2 cm) To top of high shelf - add 23 1/2” (59.7 cm)
To top of 6” backguard -add 6” (15.2 cm)
Overall depth from rear To end of side panel - 24 15/16” (63.3 cm)
To end of control panel - 27 7/8” (70.8 cm)
To end of knobs - 28 3/8” (72.0 cm)
Electrical requirements 120 VAC/60 Hz; 4 ft. (121.9 cm), 3-wire cord with grounded 3-prong plug attached to
unit.
Gas requirements Shipped natural or LP/Propane gas; field convertible with conversion kit (purchased
separately); accepts standard residential 1/2” (1.3 cm) ID gas service line.
Maximum amp usage .83 amps 6B - .83 amps 6G / 4GQ / 4K - 1.52 amps
4G - .96 amps 6Q / 4Q / 8B - 1.52 amps
4Q - .83 amps 4G - 1.89 amps
Surface burner rating 15,000 BTU Nat. / 13,500 BTU LP
(4.4 kW Nat / 4.0 kW LP)
Griddle burner rating 15,000 BTU Nat. / 13,500 BTU LP
N/A (4.4 kW Nat. / 4.0 kW LP)
Grill burner rating 12” - 1@ 18,000 BTU Nat. (5.3 kW)/ 16,000 BTU LP (4.7 kW)
N/A 24” – 2 @ 15,000 BTU Nat. (4.4 kW)/ 13,500 BTU LP (4.0 kW)
Broil rating 18,000 BTU Nat./ 16,000 BTU LP
(5.3 kW Nat. / 4.7 kW LP)
Bake rating 30,000 BTU Nat./LP Right 30,000 BTU Nat./LP
(9.8 kW Nat./LP) (9.8 kW Nat./LP)
Left 15,000 BTU Nat/LP
(4.4 kW Nat.)
Oven Interior width 23” (58.4 cm) 29” (73.7cm) Right - 23” (58.4 cm)
Left - 12 1/8” (30.8 cm)
Oven Interior height 16 1/8” (41.0 cm)
Oven Interior depth 17” (43.2 cm) Right- 17”(43.2 cm)
Left - 18 1/8”(45.9 cm)
Oven Interior overall size 3.7 cu. ft. 4.6 cu. ft. Right - 3.7 cu. ft.
Left - 2.0 cu. ft.
Approximate Shipping wt.
424 lbs. (190.8 kg) 6B - 465 lb. (209.3 kg) 6G - 624 lb. (280.8 kg)
4Q - 470 lb. (211.5 kg) 6Q - 620 lb. (279.0 kg)
4G - 475 lb. (213.8 kg) 4G - 634 lb. (285.3 kg)
4Q - 620 lb. (279.0 kg)
4GQ - 629 lb. (283.1 kg)
4K - 624 lb. (280.8 kg)
8B - 620 lb. (279.0 kg)
3
Minimum Clearances
Minimum clearances from the product to adjacent surfaces or construction:
• Below 36” (91.4 cm)
Sides - 0”
Rear - 0”
• Above 36” (91.4 cm)
Sides - 6” (15.2 cm)
Within the 6” (15.2 cm) side clearance, wall cabinets shall be no deeper than 13” (33.0 cm) and must be a
minimum of 18” (45.7 cm) above the countertop.

Viking DEVDSC305 Specifications

General

Brand	Viking
Model	DEVDSC305
Category	Ranges
Language	English
