Viking F-1 - Important Installation Information; Specifications

VIKING TECHNICAL SUPPORT 1.800.908.0884
13
! CAUTION: To Reduce the Risk of Fire or Injury to Persons:
! WARNING: For use with gates at a maximum 1500 lbs. in weight or 16 ft. in length.
IMPORTANT INSTALLATION INFORMATION
1000 lb.
Locate Control Buttons:
1. Within sight of the gate,
2. At a minimum height of 5 feet
so small children are not able to
reach it; and
3. At least 6 feet away from all
moving parts of the gate.
Specications
Maximum Gate Length: 16 ft. / 12 ft.
Maximum Gate Weight: 1000 lb. / 1500 lb.
Operating Temperature: -20ºF (-28ºC) to 158ºF (70ºC)
Power Requirements: 115v / 230v AC (4 amp / 2 amp)
Single Phase (50 Hz / 60 Hz)
DO NOT allow pedestrian use of this gate DO NOT install the gate operator to lift gates
16 ft.
1500 lb.
12 ft.
