LIMITS SETUP
! TECHNICAL TIP: Each Limit LED will illuminate solid when the the corrisponding limit
switch is actuated. The LEDs will flash simultaneously while both limit switches are
actuated at the same time. This display may indicate a problem with the limt switches or
wires.
! IMPORTANT: This gate operator uses mechanical limit switches. Therefore, the limits
cannot be set electronically by the control board. The Limit Buttons on the control
board have been rendered inactive.
“Close Limit” LED
indictates the gate
is at the close limit.
“Open Limit” LED
indictates the gate
is at the open limit.
