TECHNICAL SUPPORT 1 800 908 0884
9
CAUTION -
FOR USE WITH GATES OF A MAXIMUM OF 60 FT IN LENGTH AND 4000 LBS. IN WEIGHT.
WARNING - TO REDUCE THE RISK OF SEVERE INJURY OR DEATH TO PERSONS:
IMPORTANT INSTALLATION INFORMATIONIMPORTANT INSTALLATION INFORMATION
Specifications
Do not allow pedestrian use of this gate!
60’ maximum gate length
4000 pounds maximum gate weight
Do NOT Install the gate operator to lift gates
Locate Control Buttons:
1. Within sight of the gate,
2.
At a minimum height of 5 feet so small
children are not able to reach it,
and
3. Away from the gate opening so that
someone cannot operate the controls
while in the path of the gate, and
3. Away from all moving parts of
the gate.
Maximum Gate Length: 55 feet
Maximum Gate Weight: 4000 lbs.
Power Requirements: 120 VAC Single Phase at 6 Amps
Or
220 VAC Single Phase at 3 Amp
Operating Temperature: -20°C (-4°F) to
70°C (158°F)
CLOSE
STOP
OPEN
Control
Control
Buttons
Buttons
Control
Buttons
