OPTIONAL VIKING BLUE INSTALLATIONOPTIONAL VIKING BLUE INSTALLATION
1. Decide which Operator will be the Master
and which will be the Slave.
2a. Install the “Master” Viking Blue Module on
the Master Control Board.
2b. Install the “Slave” Viking Blue Module on
the Slave Control Board.
Use care in connecting the plug to the Control
Board. The pins are small and easily bent.
Match the white dot on the plug to the white
dot on the control board (near the JP2 legend
as depicted).
3. Install the Jumper (near the JP3 legend
depicted). Viking-Blue requires this jumper
to operate as a Master/Slave device. The
“Low Battery” LED will turn ON, indicating
the Control Board is ready for use with the
Viking-Blue Module.
4. Attach the Viking-Blue Module to the
Operator. For better communication and
performance follow these guidelines:
• The Module must be under the Operator
Cover.
• The Modules must be facing each other as
much as possible.
The Light on the Viking-Blue module will turn
green upon connection between the other Module.
Be sure to test your Master/Slave communication.
