Disassembly Procedure
WARNING
To avoid risk of electrical shock, personal injury, or death, disconnect power to unit before servicing,
unless testing requires power.
44 ©2007 Viking Preferred Service
Water Dispenser Switch Removal
Condition Requirements:
Door Opened
1. Insert small screwdriver as shown to remove
dispenser cover plate.
2. Remove screw and pull dispenser out of unit.
3. Disconnect wires from switch and remove switch
from dispenser unit.
4. Reverse procedure for installation.
Freezer Section Light Bulb Removal
Condition Requirements
CAUTION
To avoid risk of burners, wear gloves when
replacing light bulb.
Freezer Drawer Opened
1. Remove light shield by pressing the upper right side
of the shield and rotating downward.
2. Remove light bulb.
3. Replace with appliance bulb no greater than 40
watts.
Freezer Section Light Socket Removal
Condition Requirements:
Freezer Light Bulb Removed
Freezer Drawer Removed
1. Remove screw to lower light socket housing from
unit.
2. Disconnect wires from light socket.
3. Squeeze retaining tab to release socket.
4. Reverse procedure for installation.
