Viking VCSF036SS - Disassembly Procedures; Cabinet Airflow Illustration

Disassembly Procedures
©2007 Viking Preferred Service 43
Cabinet Air Flow
Freezer Back
(Air Baffle)
Evaporator
Fan Assembly
Evaporator
Compressor
Condenser
Condenser Fan
Assembly
Refrigerator Air
Return Tunnel
Air Supply
(In Foam)
Refrigerator Air
Supply Tunnel
To Fresh Food
Compartment Controls
Large Beverage Chiller
A
ir Supply (Some Models)
Small Beverage Chiller
A
ir Supply (Some Models)
Deli
Air Supply
