Specifications (DGCU Designer)
11
Designer Gas Cooktops
Description
DGCU105/106 DGCU165/166 DGCU155/156
Overall width
30-3/4” (78.1 cm) 36-3/4” (93.3 cm) 45” (114.3 cm)
Overall height from
bottom to top of glass
(including connector)
4-1/4” (10.8 cm)*
Overall depth from rear 21” (53.3 cm)
Cutout width
28-3/4” (73.0 cm) min. to
29-7/8” (75.9 cm) max.
34-1/2” (87.6 cm) min. to
35-7/8” (91.1 cm) max.
42-7/8” (108.9 cm) min. to
44-1/8” (112.1 cm) max.
Cutout height 2-3/4” (7.0 cm)
Cutout depth
19-11/16” (50.0 cm) min. to 20-1/2” (52.1 cm) max.
Gas requirements Not field convertible – Must be ordered from factory either natural or LP/Propane.
Uses standard residential 1/2” (1.3 cm) I.D. gas service line.
Electrical requirements
120 VAC/60 Hz; 4 ft. (121.9 cm), 3-wire cord with grounded
3-prong plug attached to product.
Maximum amp usage 2.0 amps
Surface element rating
Left front
Left rear
Left center
Right center
Right front
Right rear
16,000 Nat./12,500 LP (BTU)
(4.1 Nat./4.0 LP (kw))
12,000 Nat./11,000 LP (BTU)
(3.5 Nat./2.8 LP (kw))
N/A
N/A
6,000 Nat./LP (BTU)
(1.8 Nat./LP (kw))
8,000 Nat./LP (BTU)
(2.1 Nat./LP (kw))
12,000 Nat./11,500 LP (BTU)
(4.1 Nat./4.0 LP (kw))
10,000 Nat./10,000 LP (BTU)
(3.5 Nat./2.8 LP (kw))
16,000 Nat./12,500 LP (BTU)
(2.9 Nat./LP (kw))
N/A
6,000 Nat./LP (BTU)
(1.8 Nat./LP (kw))
8,000 Nat./LP (BTU)
(2.1 Nat./LP (kw))
12,000 Nat./11,500 LP (BTU)
(3.5 Nat./2.8 LP (kw))
8,000 Nat./LP (BTU)
(2.1 Nat./LP (kw))
10,000 Nat./LP (BTU)
(2.9 Nat./LP (kw))
16,000 Nat./12,500 LP (BTU)
(4.1 Nat./4.0 LP (kw))
8,000 Nat./LP (BTU)
(2.1 Nat./LP (kw))
6,000 Nat./LP (BTU)
(1.8 Nat./LP (kw))
Approximate
shipping weight
67 lbs. (30.2 kg) 80 lbs. (36.0 kg) 96 lbs. (41.9 kg)
Dimensions (DGCU Designer)
10
21”
(53.3 cm)
30-3/4”
(78.1)
21”
(53.3 cm)
36-3/4”
(93.3 cm)
21”
(53.3 cm)
45”
(114.3 cm)
30” Gas Cooktop 36” Gas Cooktop
45” Gas Cooktop
5-3/8”
(13.7 cm)
4-1/4”*
(10.8 cm)
Front view
Note: When using a 90˚ elbow supplied by installer, minimum cutout is 5-5/8” (14.3 cm)
