VOADDR5361 - 36” DOOR / DRAWER
Cutout Dimensions
TOP VIEW
SIDE
VIEW
FRONT
VIEW
20”
(50.8 cm)
Deep
1-1/2”
(3.8 cm) MIN
3-1/2” (7.6 cm)
MIN
33-3/4” (85.7 cm)
19”
(48.3 cm)
High
19”
(48.3 cm)
20”
(50.8 cm)
SIDE
VIEW
19”
(48.3 cm)
20-3/8”
(51.8 cm)
1-1/4”
(3.2cm)
2-5/8”
(6.7 cm)
18-3/4”
(47.6 cm)
FRONT
VIEW
36”
(91.4 cm)
16-5/8”
(42.2 cm)
21-1/8”
(53.7 cm)
18-3/8”
(46.7 cm)
9-1/4”
(23.5 cm)
15-1/8”
(38.4 cm)
Product Dimensions
TOP
VIEW
15-1/2”
(39.4 cm)
19”
(48.3 cm)
21-5/8”
(54.9 cm)
33-5/8”
(85.4 cm)
15-1/8”
(38.4 cm)
Clearance
Radius
