22
NOTE: Sometimes momentarily turning the pump off and
on will help it to prime. Do not do this more than 5 times. If the
pump(s) will not prime, shut off the power to the spa and call for
service.
Once you have completed priming, the home status screen will
display the set temperature. e system requires approximately
1-2 minutes of water flowing through the heater to determine and
display the correct water temperature.
Home/Status Screen
e Home/Status screen on your X Series (X500) control shows
basic statuses including: time, jet status, light status, current water
temperature, spa operation mode, and heating/cooling status. In
addition, many of the basic functions of operating your spa can
be performed with one touch from the Home/Status screen. In
addition, any necessary error or maintenance messages will appear
at the bottom of the screen.
Start or Stop Accessories
To start or stop an accessory (jets, lights, etc.), press the associated
button. Icons will become animated when their accessory is turned
on, and inanimate when turned off. Icons on the screen will reflect
the speed or state of the devices running on your spa. When
an accessory has more than two states, press the button until it
reaches the desired state.
Light Operation
Turn lights on and off using the button. Press once to turn
lights on. Press again to turn off. Pressing the button repeatedly
will cycle through light modes and colors (flashing, fading, solid
color).
Screen Rotation/Mode Button
From the home status screen you may press the button to
rotate the screen 180 degrees for easier viewing from inside the
spa.
Adjusting the Set Temperature
e water temperature is displayed near the bottom of the home
status screen. Press the and buttons to set the desired
temperature. e set point will appear in large type. Press again
immediately to adjust the set point to your desired temperature. If
there is no change to the preset temperature value for 3 seconds,
the Home/Status screen appears again, showing the current water
temperature in the upper right corner.
When the set value is lower than the current temperature
“Cooling to xx.x” will appear at the bottom of the screen. When
the set value is higher than the current temperature, “Heating to
xx.x” will be indicated. Normally there is a short delay before the
heating starts, during which “Heating suspended” is indicated
under the value. When the water temperature reaches your set
point a message of “Set point reached” will appear.
Spa Settings
e settings on the X Series (X500) control pad are navigated by
the use of the (Settings) button. One press gives you access
to several menus where you can manage the specific settings of
your spa. After pressing the Settings button you may navigate
to each submenu by pressing the and buttons and then
using the (Light) button to select a submenu.
When using the Settings menu or submenus the screen will
revert back to the Spa mode and Home/Status screen if no key
is pressed for 60 seconds. Note that if an accessory is not present
in your spa configuration, its menu will not appear. Refer to
the following section to get details about the possible settings,
accessories, and their detailed functionalities.
Water Care
e Water Care submenu will help you set up your ideal filtration
and heating settings. Choose from Away from Home, Standard
- Beginner, Energy saving, Super energy saving, and Weekender,
depending on your needs and preferences.
Use the (Light) button to select your setting. A check mark
will appear within the selected icon to confirm your selected
mode.
In the descriptions of each mode below “Economy mode” means
that the set point will be reduced by 7°C*, which means that the
heating system will not be engaged unless the temperature falls to
7°C below the spa’s set temperature.
e filtration schedule shown on the screen will apply to the main
filtration pump. If your spa uses a circulation pump configured to
run 24 hours, the screen will show you the purge setting instead
of filtration. e purges are pre-programmed for a fixed number
of minutes, therefore the duration will be set to N/A on the
screen, and only the start time can be modified.
Water Care Modes
Away: In Away mode the spa temperature set point will be
reduced by 7°C (see description of “Economy mode” above). Spa
will remain in Economy mode at all times of the day and all days
of the week.
Standard - Beginner: In Standard mode the spa will heat to the
set point and filter according to the spa’s standard configuration.
Spa will heat to set point at all times and all days of the week.
Energy Savings: In Energy Savings mode the spa temperature
set point will be reduced by 7°C (see description of “Economy
mode” above) during peak daytime hours. Spa will heat to normal
set point during evening hours and on the weekend.
Super Energy Savings: In Super Energy Savings mode
the spa temperature set point will be reduced by 7°C (see
description of “Economy mode” above) during peak daytime
