3.6 - Decoupling coil (CHOKE)
The decoupling coil allows the power supply and the logic
and control signals to travel on a single pair.
The construction for EN 50022 guide mount is available in a
single version:
01842: occupies two 17.5 mm modules, grey RAL 7035
IN OUT
492.1842X 0A XXXX VIMAR - Marostica - Italy
+ – + –
01842
CHOKE
29 VUN
= 320 mAIN
01842
Technical specifications
• Rated voltage: 29 V d.c.
• Rated current: 320 mA
