ENGLISH - 25
1 2 3 4 5 6 7 8
ON
1
O
N
2 3 4 5 6 7
1 2 3
ON
5.1.4
Place dip-switch 1 in the ON position.
The LED lights up yellow.
5.1.3
Select the desired address (see “Address
selection” table on page 8).
In the example, address A was used.
5.1.5
When the LED turns green (after about
15 seconds), insert the smart card to be
programmed.
1 2 3
ON
5.1.8
To exit the procedure, place dip-switch 1 in
the OFF position. The LED switches off.
5.1.6
When the LED turns off, the smart card
has been programmed.
5.1.7
Remove the smart card.
The LED turns green again, waiting for
other smart cards to program.
To program additional smart cards,
repeat the procedure from step 5.1.5.
