Vimar ELVOX 41018

• Navigation: Direct/Navigable/Expanded
Edits the style of the home page viewed
and related access modes to the available
functions.
Contacts
Porter
Select
Contacts
Porter
SEARCH BY
NAME
CALL BY No
OPEN WITH
CODE
PORTER
Direct Navigable Extended
LCD
This lets you dene the operating parameters of the display
• Brightness: 0-5
Brightness level. When there are high internal temperatures, the display is automatically dimmed.
• Colours: B/N, BLUE, GREEN
Used to select one of the predened colour
schemes for viewing the menu, according
to readability.
Extension
Delete
Confirm
Extension
Delete
Confirm
Extension
Delete
Confirm
B/W BLUE GREEN
• Standby: ON, OFF
Lets you disable display standby mode, i.e. not decreasing the brightness level of the LCD when it is not being used.
Logo (*)
Used to Enable/Disable the uploaded logo display.
If ON is selected, after 30 seconds of inactivity in the home the stored logo is displayed.
The logo image is programmed in SaveProg. It must be entered in BMP format with a xed size of 320x320 pixel and colour depth
24 bit. The image is then converted into a palette of 256 colours.
A 120x320 pixel area is reserved at the bottom for a welcome message, customisable in SaveProg, with maximum length 30 char
-
acters. If no string is entered on the display the default wording is shown, “Press to continue”.
Once the logo is displayed, press any key to return to the home page. The only e󰀨ect of this is to hide the logo and return to the set
home page. From the home page it is possible to run the required function.
3.3.1.5. Outdoor Station
This section lets you set the basic parameters of the audio/video module of the outdoor station.
Audio
This lets you set the operating levels of the speaker and microphone.
• Speaker
• Microphone.
(*)
33
EN
41018
